windows中怎么使用Nginx搭建图片服务器

1.进入官网下载nginx压缩包，解压后目录如下

2.在解压后的conf/nginx.conf配置文件中，添加添加或者修改带有颜色地方的代码

#user nobody; worker_processes 1; #error_log logs/error.log; #error_log logs/error.log notice; #error_log logs/error.log info; #pid logs/nginx.pid; events { worker_connections 1024; } http { include mime.types; default_type application/octet-stream; #log_format main '$remote_addr - $remote_user [$time_local] "$request" ' # '$status $body_bytes_sent "$http_referer" ' # '"$http_user_agent" "$http_x_forwarded_for"'; #access_log logs/access.log main; sendfile on; #tcp_nopush on; #keepalive_timeout 0; keepalive_timeout 65; #gzip on; server { listen 8089; server_name localhost; #charset utf-8; #access_log logs/host.access.log main; #添加博客的代码 location ~ .*\.(gif|jpg|jpeg|png)$ { expires 24h; root g:/images/;#指定图片存放路径 access_log g:/images/log;#图片路径 proxy_store on; proxy_store_access user:rw group:rw all:rw; proxy_temp_path g:/images/;#图片路径 proxy_redirect off; proxy_set_header host 127.0.0.1; proxy_set_header x-real-ip $remote_addr; proxy_set_header x-forwarded-for $proxy_add_x_forwarded_for; client_max_body_size 10m; client_body_buffer_size 1280k; proxy_connect_timeout 900; proxy_send_timeout 900; proxy_read_timeout 900; proxy_buffer_size 40k; proxy_buffers 40 320k; proxy_busy_buffers_size 640k; proxy_temp_file_write_size 640k; if ( !-e $request_filename) { proxy_pass http://169.254.140.133:8089; #代理访问地址 } } location / { root html; index index.html index.htm; } #error_page 404 /404.html; # redirect server error pages to the static page /50x.html # error_page 500 502 503 504 /50x.html; location = /50x.html { root html; } # proxy the php scripts to apache listening on 127.0.0.1:80 # #location ~ \.php$ { # proxy_pass http://127.0.0.1; #} # pass the php scripts to fastcgi server listening on 127.0.0.1:9000 # #location ~ \.php$ { # root html; # fastcgi_pass 127.0.0.1:9000; # fastcgi_index index.php; # fastcgi_param script_filename /scripts$fastcgi_script_name; # include fastcgi_params; #} # deny access to .htaccess files, if apache's document root # concurs with nginx's one # #location ~ /\.ht { # deny all; #} } # another virtual host using mix of ip-, name-, and port-based configuration # #server { # listen 8000; # listen somename:8080; # server_name somename alias another.alias; # location / { # root html; # index index.html index.htm; # } #} # https server # #server { # listen 443 ssl; # server_name localhost; # ssl_certificate cert.pem; # ssl_certificate_key cert.key; # ssl_session_cache shared:ssl:1m; # ssl_session_timeout 5m; # ssl_ciphers high:!anull:!md5; # ssl_prefer_server_ciphers on; # location / { # root html; # index index.html index.htm; # } #} }

3.点击绿色的nginx.exe图标，启动服务器，在任务管理器看到如下，则启动成功

4.在浏览器中输入http://127.0.0.1:8089可以看到

5.在g:/images/下，放一个图片，在浏览器地址栏输入http://127.0.0.1:8089/img.jpg,就可以访问到服务器上的图片
